Manufactured in Foshan, China by Foshan Aludex Doors & Windows Co., Ltd., our aluminum doors with glass integrate structural 6063-T5 aluminum extrusions with certified safety glass. Designed specifically for luxury villa entrances, high-end residential projects, and commercial buildings, these door systems maximize ambient indoor light while maintaining robust intruder resistance and thermal weatherproofing.
Engineered with heavy-wall profiles up to 5.0mm structural thickness, ensuring zero warping under extreme thermal cycles and wind pressure.
Configurations include double-glazed thermal break panels, frosted privacy glass, low-E coatings, and laminated impact safety glass.
Advanced surface treatments including polar black powder coating and heat-transfer wood grain, guaranteed against chalking and UV fading.
Pre-routed at our factory to seamlessly fit embedded smart locks, biometric handle units, and mechanical multi-point locking mechanisms.
Explore our standard structural models below. Every model can be customized in profile depth, plate thickness, glass spec, finish color, and locking hardware to meet your CAD shop drawings.
Constructed with 4mm front + 3mm rear aluminum plates and a 100×65×5.0mm structural frame, featuring integrated vertical glass daylighting panels.
High-security entrance door incorporating an 8mm front plate with wood-grain transfer finish and precision CNC-fitted architectural glass inserts.
Features a 6mm reinforced front aluminum panel with side glass lights, delivering refined symmetry and optimal thermal retention.
Modern luxury villa entry leaf with integrated glass panels, engineered for smooth operation on heavy-duty concealed hinges or pivot sets.
Framed glass entrance door with multi-cavity thermal break structure, customized for weather-sealed residential and commercial facades.
Precision CNC-engraved aluminum panel coupled with dual-side safety tempered glass, balancing elegant design with robust anti-burglar protection.
Armored-grade aluminum entry door featuring a massive 15mm solid front plate, high-strength frame, and decorative bullet-resistant glass option.
Sleek, modern minimalist framed glass door for single or double leaf configurations. Available with matching transoms and sidelights.
Versatile aluminum entry door featuring geometric glass panel geometry and a weather-proof polar black surface treatment.
Foshan Aludex Doors & Windows Co., Ltd. operates an integrated manufacturing process from raw aluminum profile extrusion to pre-treatment, CNC engraving, assembly, and quality testing.
We utilize prime 6063-T5 aluminum profiles. Depending on door dimensions and wind load requirements, buyers can select T65 (65mm depth), T85 (85mm depth), T93 (93mm depth), or D100 (100mm depth) system profiles with structural wall thickness from 2.0mm to 5.0mm.
Glazing units are pre-sealed into the door leaf frame during assembly. Options include 5mm+12A+5mm tempered double glazing, laminated safety glass, low-E coated glass, frosted privacy glass, and decorative grill inserts tailored to local building codes.
Finished with outdoor-grade fluorocarbon (PVDF) powder coating or heat-transfer wood-grain technology. Resists corrosion, salt spray, moisture, and intense solar radiation without peeling or discoloration.
Standard engineering parameters provided by Foshan Aludex Doors & Windows Co., Ltd. for project drawing evaluations:
| Parameter | Standard Residential | Heavy Villa / Project | Armored Security Glass Door |
|---|---|---|---|
| Aluminum Alloy Grade | 6063-T5 Profile | 6063-T5 Heavy Profile | 6063-T5 High Tensile |
| Front Plate Thickness | 4mm - 6mm | 6mm - 8mm | 8mm - 15mm Solid Plate |
| Frame Outer Depth | 65mm (T65 Series) | 85mm - 93mm (T85/T93) | 100mm (D100 Series) |
| Glazing Type | Tempered Double Glazed | Insulated Low-E / Laminated | High-Impact Security Glazing |
| Lock Compatibility | Mechanical / Surface Smart Lock | Handle-Embedded Smart Lock | Multi-Point Armored Lock Set |
Common questions regarding ordering, customization, and quality control from Foshan Aludex Doors & Windows Co., Ltd.
We offer tempered safety glass, double glazed insulated units (IGU), triple glazing, low-E energy efficient glass, frosted privacy glass, laminated security glass, and smart switchable glass integrated into our 6063-T5 aluminum frames.
Yes. Our thermally broken aluminum profile series (such as the D100 series) combined with insulated double or triple glazing effectively prevent thermal transfer, control condensation, and offer high structural resistance against severe weather and wind pressures.
Foshan Aludex Doors & Windows Co., Ltd. provides full OEM/ODM flexibility: custom structural dimensions, profile depths (T65, T85, T93, D100), surface finishes (fluorocarbon powder coating, wood-grain heat transfer, anodizing), custom glass inserts, pre-drilled smart lock housing, and export-grade crating.
Every door leaf and glass frame is wrapped with protective surface film, corner guards, multi-layer foam padding, and packed inside fully enclosed fumigation-free wooden crates or steel-reinforced export pallets.
Send your project opening dimensions, target glass specifications, CAD drawings, or quantity requirements directly to our engineering department. Foshan Aludex Doors & Windows Co., Ltd. will review your requirements and provide detailed shop drawings and factory-direct pricing.
